You cannot toggle a lightweight component's display Off using the checkbox in the Structure Tree. This option is disabled when Load model in background is unchecked. Load lightweight only to open external components as lightweight graphics representations when opening SCDOC files.
Load model in background to orient large designs while they are loading. You can hover over the icon to see a tooltip that will explain the valid values for the option. or the DS Mechanical Options dialog, you will see a red exclamation mark icon next to the field. If you try to enter a value that is out of the allowed range in the Options panel Area of the user interface that enables you to modify functions specific to tools. Click OK to save all your changes and close the DS Mechanical Options dialog.Select a file type in the panel on the left to change options for just that type of file.ĭescriptions of all options are listed below.
Select DS Mechanical Options from the File menu to display the DS Mechanical Options window.Ĭlick File Options in the navigation panel on the left. If you work frequently with non-DS Mechanical files, we recommend that you set your file options to optimize the importing and exporting process for your needs. You can open and insert files from many other modeling applications into DS Mechanical for editing, and save your DS Mechanical designs as many different file types. You are here: Customizing DesignSpark Mechanical > File import and export options
